European electric hoist

Direct supply from the manufacturer: Whatsapp： +86 18118868683; E-mail：kitocrane@163.com

Detail

The European-style electric hoist, combining advanced European technology with local innovation, demonstrates superior performance, surpassing traditional domestic electric hoists. Its unique charm and superior performance have made it a leader in the electric hoist market. By combining European expertise with local innovation, it not only enhances the efficiency of traditional electric hoists but also demonstrates its exceptional capabilities in a wide range of applications. Since its introduction, the European-style electric hoist has been well-received by customers and has become a new favorite in the market.

Features:
① C-shaped design, compact structure, lightweight
② Selected high-quality components, modular design, safe and reliable
③ Precise positioning, efficient operation, and improved production efficiency
④ Intelligent control system, user-friendly design, and easy operation
⑤ Green and energy-saving, reducing operating costs

Product Specifications
Lifting capacity: 3.2t

Lifting height.(m)	Working dutyFEM(GB)	Lifting speed(m/min)	Lifting moton.(kw)	Traveling speec(m/min)
6	2m(M5)	0.8/5	0.45/3.2	5-20
9	2m(M5)	0.8/5	0.45/3.2	5-20
12	2m(M5)	0.8/5	0.45/3.2	5-20

Lifting capacity 5t

Lifting height.(m)	Working dutyFEM(GB)	Lifting speed(m/min)	Lifting moton.(kw)	Traveling speec(m/min)
6	2m(M5)	0.8/5	1/6.1	5-20
9	2m(M5)	0.8/5	1/6.1	5-20
12	2m(M5)	0.8/5	1/6.1	5-20
15	2m(M5)	0.8/5	1/6.1	5-20
18	2m(M5)	0.8/5	1/6.1	5-20

Lifting capacity 10t

Lifting height.(m)	Working dutyFEM(GB)	Lifting speed(m/min)	Lifting moton.(kw)	Traveling speec(m/min)
6	2m(M5)	0.8/5	1.5/9.5	5-20
9	2m(M5)	0.8/5	1.5/9.5	5-20
12	2m(M5)	0.8/5	1.5/9.5	5-20
15	2m(M5)	0.8/5	1.5/9.5	5-20
18	2m(M5)	0.8/5	1.5/9.5	5-20

Lifting capacity 20t

Lifting height.(m)	Working dutyFEM(GB)	Lifting speed(m/min)	Lifting moton.(kw)	Traveling speec(m/min)
6	1Am(M4)	0.66/4	2.6/16	5-20
9	1Am(M4)	0.66/4	2.6/16	5-20
12	1Am(M4)	0.66/4	2.6/16	5-20
15	1Am(M4)	0.66/4	2.6/16	5-20
18	1Am(M4)	0.66/4	2.6/16	5-20
