RY type electric hoist

  • RY hoist is a novel European-style wire rope electric hoist with a coordinated and beautiful overall appearance
Direct supply from the manufacturer
Whatsapp: +86 18118868683
E-mail:kitocrane@163.com

Detail

RY type electric hoist
RY hoist is a novel European-style wire rope electric hoist with a coordinated and beautiful overall appearance. It adopts aluminum alloy shell, which has the characteristics of light weight and compact appearance, which meets the national energy conservation and environmental protection requirements. The whole machine has a high energy efficiency level and is suitable for low-building house structures.
RY gourd sales type in China:
Compact structure, light weight, low wheel pressure, saving operating costs.
 Aluminum alloy shell, fast heat dissipation and long life.
3.2t and 5t adopt self-developed hoisting motor, which is cost-effective.
 The lifting speed of 3.2t and 5t reaches 7m/min, which is higher than similar domestic products (5m/min), and can complete the operation at high speed and efficiency.
 The hoist has a high level of work (M5), which expands the applicable occasions.
 The noise of the whole machine is lower than 80dB (National standard requirement: no more than 85dB).
 The energy efficiency rating of the whole machine is Level 2, which meets the national energy conservation and environmental protection requirements.
Adopting mature and reliable control methods and electrical components, with protection functions such as emergency stop, loss of pressure, anti-overload, and anti-lifting hook.
The electrical components are installed on guide rails, which makes maintenance, maintenance and replacement more convenient.
 The control box is equipped with a shock-absorbing rubber pad to minimize the impact of vibration on the electronic control system.
 The pulley override is 1/4, and the left and right displacement of the hook is small during the up and down operation.
Using high-strength steel wire rope, wear resistance and prolong service life.
Using high-strength nylon rope guides, which can prevent the wire rope from arching, falling off the groove and rope disorder.
The double-speed hoist is configured with full frequency conversion for lifting and running, using imported brand frequency converters.
RY gourd sales type in China
Lifting capacity (t): 3.2, 5, 10
Lifting height (m): 6, 9, 12



RY Gourd Global Sales Type:
Based on the Chinese sales model, it has the following characteristics:
Adopt the brake and hoisting motor specially designed by Japan KITO Company, which has reliable braking and long service life.
Adopting advanced control system, both lifting and running are frequency conversion double speed, and imported from Japan frequency converter control, starting and braking are stable, and the impact is small.
 The lifting control has a light-load high-speed function. When the load is less than 25% of the rated load, the lifting will automatically switch to 1.5 times high-speed operation to improve the efficiency of hoist operation.
 Mature technology and stable quality. Since its launch in 2016, it has been favored by customers in Japan, the United States, Thailand, Brazil and other places. It is also suitable for various applications in the domestic market.
RY gourd global sales type
Lifting capacity (t): 3.2, 5
Lifting height (m): 6, 9, 12
To get the latest price, please contact us, we will reply as soon as possible (within 12 hours)
